Speeds
1 x 7
Weight
14.2 kg (31.3 lb)
Gear Inches
34" - 83" (2.71 - 6.62 m)
Folding Size
39 × 86 × 84 cm (15.4 × 33.9 × 33.1 in)
Folding Time
10 seconds
Frame Sizes
One size
Distance: Seatpost to Handlebar
67 - 73 cm (26.4 - 28.7 in)
Distance: Saddle to Pedal
79.5 - 105 cm (31.3 - 41.3 in)
Suggested Rider Height
148 - 195 cm (58.3 - 76.8 in)
Max Gross Vehicle Weight
120 kg (264.6 lb)
Max Rider Weight
105 kg (231.5 lb)
Frame
Tern Node, aluminum, OCL+ joint, 2 patented technologies
Fork
Integrated, hi-tensile steel
Handlepost
Tern Physis 3D (G2), 3D forged, 5 patented technologies, 12°, 290 mm
Stem
Tern Andros, adjustable, forged construction, patented technology
Headset
Flux, cartridge bearings, Physis integrated
Handlebar
Tern Sweep, 6061-Al, Tern Andros butted
Grips/Bar Tape
Velo ergonomic, lock-on
Saddle
BioLogic Como DLX
Seatpost
SuperOversize, 6061-Al, micro-adjust clamp
Seatpost Clamp
SuperOversize, 6061-AL
Front Brake
V, aluminum, linear spring
Rear Brake
V, aluminum, linear spring
Brake Levers
V, aluminum bracket/lever
Brake Cable & Housing
Anti-compression housing, slick cables
Front Hub
Aluminum; Opt: Shimano 1.5W dynamo
Rear Hub
Shimano Nexus 7 freewheel
Spokes & Nipples
Stainless steel
Rims
Doublewall aluminum
Tires
Schwalbe Big Apple, 50-507, puncture protection, Reflex
Shifter(s)
Shimano Nexus, 1 x 7 spd
Crankset
Cold-forged 6061 aluminum crank arms, hand-polished
Cassette/Freewheel
17T
Bottom Bracket
Cartridge, sealed bearings
Chain
408H, 3/32"
Pedals
Folding, alloy body
Shifter Cable & Housing
Shimano
Bell
Aluminum
Chainguard
BioLogic FreeDrive
Kickstand
Deluxe center mount
Clip System
Magnetix 2.0
Luggage Socket
Yes
Front Light
Opt: Tern Valo 2
Rear Light
Opt: Deluxe LED
Fenders
Freelance, stainless hardware
Rack(s)
Tern Freight Rack; Max load weight: 25 kg (55 lb)
