Color
Black/Gray/Red
White/Gray/Orange
Wheel Size:
26" wheels
Speeds:
2 x 10
Weight:
12.22 kg (26.9 lb)
Folding Size:
38 x 90 x 81 cm (15" x 35.4" x 31.9")
Folding Time:
10 sec
Frame Sizes:
One size
Gear Inches:
26" - 112" (2.09 - 8.92 m)
Distance: Seatpost to Handlebar:
Min: 630 mm (24.8") Max: 700 mm (27.6")
Distance: Saddle to Pedal:
Min: 770 mm (29.7") Max: 1040 mm (40.6")
Suggested Rider Height:
148 - 195 cm (4'10" - 6'5")
Max Load Weight:
105 kg (230 lb)
Frame:
Tern Eclipse, hydroformed 7005-Al w/ smooth TIG welding, 3 patented technologies
Fork:
Tarsus, 6061-AL, hydroformed
Handlepost:
Tern Physis 3D, 3D forged, 5 patented technologies
Stem:
Syntace VRO, adjustable
Headset:
Flux, cartridge bearings, Physis integrated
Handlebar:
Kinetix Comp, 6061-Al, VRO butted
Grips/Bar Tape:
BioLogic Arx
Saddle:
Tern Porter+, patented GripPad design, PrimeGel padding
Seatpost:
SuperOversize, 6061-Al, forged clamp
Seatpost Clamp:
Syntace OverLock
Front Brake:
Tektro Auriga, hydraulic disk
Rear Brake:
Tektro Auriga, hydraulic disk
Brake Levers:
Tektro Auriga, hydraulic disk
Brake Cable & Housing:
Tektro Auriga, hydraulic
Front Wheel:
Kinetix Pro Disk, Paired Spoke technology, Shimano Centerlock, 20H
Rear Wheel:
Kinetix Pro Disk, Paired Spoke technology, Shimano Centerlock, 20H
Spokes And Nipples:
Double-butted 18/10 stainless, Sapim Polyax nipples
Tires:
Schwalbe Kojak, 35-559, foldable, puncture protection, 95 psi
Shifter(S):
Shimano Tiagra trigger, 2 x 10 spd
Front Derailleur:
Shimano Tiagra
Rear Derailleur:
Shimano Tiagra
Crankset:
FSA Vero, 50/34T
Cassette/Freewheel:
Shimano Deore, 11-32T, 10 spd
Bottom Bracket:
Cartridge, sealed bearings
Chain:
KMC X10
Pedals:
LiteForm QR, alloy body, QR right/standard left
Shifter Cable & Housing:
Jagwire LEX-SL, slick treatment, alloy ferrules
Bell:
Pitch, brass
Kickstand:
Premium center mount
Clip System:
Magnetix 2.0
Luggage Socket:
Yes
Rear Light:
BioLogic TailLight
Accessory:
Pedal Holder
