Speeds
1 x 8
Weight
23.7 kg (52.2 lb)
Gear Inches
35" - 85" (2.78 - 6.81 m)
Folding Size
38 × 156 × 79 cm (15 × 61.4 × 31.1 in)
Folding Time
5 sec
Frame Sizes
One size
Distance: Seatpost to Handlebar
45 - 52 cm (17.7 - 20.5 in)
Distance: Saddle to Pedal
70 - 100 cm (27.6 - 39.4 in)
Suggested Rider Height
147 - 190 cm (57.9 - 74.8 in)
Max Gross Vehicle Weight
140 kg (308.6 lb)
Max Rider Weight
120 kg (264.6 lb)
Frame
Tern NBD, 6061-AL, Patented design, EFBE Tri-Test approved: 140 kg
Fork
Tern Tarsus, 6061-AL, hydroformed, EFBE approved: 140 kg
Handlepost
Tern Physis 3D, 3D forged, 5 patented technologies, 12°, 350 mm
Stem
Tern Andros, adjustable, forged construction, patented technology
Headset
Tern Flux by FSA, cartridge bearings, Physis integrated
Handlebar
Tern Sweep, 6061-AL, Tern Andros adapted
Grips/Bar Tape
Ergon
Saddle
Tern Upright by Velo
Seatpost
Tern RideEasy Suspension, 34.9 mm
Seatpost Clamp
Tern Collar
Front Brake
Shimano, hydraulic disk
Rear Brake
Shimano, hydraulic disk
Brake Levers
Shimano, hydraulic disk
Brake Cable & Housing
Shimano, hydraulic disk
Front Hub
Shimano disk
Rear Hub
Shimano Nexus 8
Spokes & Nipples
Stainless steel
Rims
Kinetix Comp, for disk
Tires
Schwalbe Big Apple, 55-406, puncture protection, Reflex
Shifter(s)
Shimano 8 spd.
Crankset
Tern NBD custom, forged 6061-AL crankarm
Cassette/Freewheel
16T
Chain
KMC for eBike, EPT corrosion resistant coating
Pedals
MKS Platform, Tern custom design
Shifter Cable & Housing
Shimano
Motor
Class 1, Bosch Active Line Plus, 270% Assist, 50 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)
Battery
Bosch PowerPack 400
Display
Bosch Intuvia, 4 mode selectable, walk assist
Range
54 -108 km (34-67 mi)
Charger
Bosch Standard Charger
Bell
Aluminum
Chainguard
Tern Custom, full chain cover
Kickstand
Ursus, rear mount
Luggage Socket
Combo Mount
Front Light
Tern Valo Direct, 190 lumens
Rear Light
Herrmans
Fenders
SplashGuard, stainless hardware
Rack(s)
Gaia Rack, 27 kg capacity, Vertical Parking
Frame Lock
ABUS, keyed-alike with Bosch battery
