Speeds
1 x 11
Weight
28.1 kg (61.9 lb)
Gear Inches
32" - 104" (2.54 - 8.32 m)
Folding Size
165 × 39.5 × 87 cm (65 × 15.6 × 34.3 in)
Folding Time
5 seconds
Frame Sizes
One size
Distance: Seatpost to Handlebar
52 - 62.5 cm (20.5 - 24.6 in)
Distance: Saddle to Pedal
76 - 110 cm (29.9 - 43.3 in)
Suggested Rider Height
150 - 195 cm (59.1 - 76.8 in)
Max Gross Vehicle Weight
180 kg (396.8 lb)
Max Rider Weight
120 kg (264.6 lb)
Frame
Tern HSD, 6061-AL, patented design, Tern sliding dropouts, EFBE Tri-Test approved: 180 kg
Fork
Suntour custom for Tern, 1.5" tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE approved: 180 kg
Handlepost
Tern Physis 3D, 3D forged, 5 patented technologies, 12°, 290 mm
Stem
Tern Andros, adjustable, forged construction, patented technology
Headset
Tern Flux Pro Taper by FSA, 1.5", angular contact bearings, Physis integrated
Handlebar
Tern Sweep, 6061-AL, Tern Andros adapted
Grips/Bar Tape
Ergon
Saddle
Tern Upright by Velo
Seatpost
Cane Creek Thudbuster G4, Tern Telescope, 34.9/30.9 mm
Seatpost Clamp
Tern Collar
Front Brake
Magura MT4, hydraulic disk, 180 mm rotor
Rear Brake
Magura MT4, hydraulic disk, 160 mm rotor
Brake Levers
Magura MT4 e-stop, hydraulic, with brake light sensor
Brake Cable & Housing
Magura, hydraulic
Front Wheel
Tern Atlas H, cargo wheel
Rear Wheel
Tern Atlas H, cargo wheel
Front Hub
Novatec, Thru-axle, sealed bearings
Rear Hub
Novatec, sealed cartridge bearing, disk
Spokes & Nipples
Stainless steel, double-butted
Rims
Tern Atlas H, wide 35 mm
Tires
Schwalbe Big Ben, 55-406, RaceGuard puncture protection, ECE-R75 ebike certification
Shifter(s)
Shimano Deore, 1 x 11 spd
Rear Derailleur
Shimano Deore Shadow+
Crankset
Tern HSD custom
Cassette/Freewheel
11-36T, 11 spd
Bottom Bracket
Motor integrated
Chain
KMC 11 spd, for eBike, EPT corrosion resistant coating
Pedals
Urban with non-slip surface, sealed bearings
Shifter Cable & Housing
Jagwire LEX-SL, slick treatment, alloy ferrules
Motor
Bosch Performance Sport, 340% Assist, 75 Nm Torque, Class 3 max speed 28 mph
Battery
Bosch PowerPack 545
Display
Bosch Kiox 300 w/ LED remote, 4 mode selectable, walk assist, connectivity with Bosch eBike Flow app, electronic bike lock
Lock & Alarm
Bosch Connect Module, GPS/GSM connectivity; 1 year free cell connectivity, Anti-theft alarm
Range
545 Wh: 51-121 km (32-76 mi)
Charger
100-240V, 4A (US)
Bell
Pitch Plus, brass
Chainguard
Custom Bash Guard
Kickstand
Ursus, rear mount
Luggage Socket
Combo Mount
Front Light
Ignis Headlight, Ultra wide 700 lumens, Hi/Lo Beam
Rear Light
RearStop Brake Light, Always on
Fenders
SKS, stainless hardware
Rack(s)
Atlas H rack, Atlas Rack Mount, 6 point mounting, 80 kg capacity
Frame Lock
ABUS, keyed-alike with Bosch battery
